DSRL – A Quick TutorialThis qui ck tutorial will show you t he ke y fe atures of the ISO/IEC 19757-8 Document Schema Renaming L anguage (DSRL) and de monstrate how DSRL (pronounc ed “ disrule”) can be used to convert XML files in local dialects to a form that can be proc essed by a n ge neralized schema.What does DSRL do?DSRL allows you t o c onvert element na me, attribute na mes, attribute va lues tokens, entity na mes and proc essing i nstruction na mes from locally m eaningful na mes to the na mes imposed by validation s chemas. It contains the fol lowing opt ions that can be used to c reate a translation m ap:1.For e ach e lement whose na me you w ant to m ap to that in a va lidation s chema create a rul e of t he form : schema-element-name 2.For e ach a ttribute whose na me you w ant to m ap to that in a va lidation s chema create a rul e of t he form : schema-attribute-name 3.For e ach a ttribute va lue token w hose na me you w ant to m ap to that in a va lidation s chema create a rul e of the form : my-value1 schema-value1 my-value2 schema-value2 4.For e ach of e ntity w hose na me you w ant to m ap to that in a n e ntity set a rul e of the form : ...

Informations

Publié par	Nasor
Nombre de lectures	10
Langue	English

Extrait

What does DSRL do? DSRL allows you to convert element name, attribute names, attribute values tokens, entity names and processing instruction names from locally meaningful names to the names imposed by validation schemas. It contains the following options that can be used to create a translation map: 1. Foreach element whose name you want to map to that in a validation schema create a rule of the form: <dsrl:elementnamemap target="myelementname"> schema-element-name </dsrl:element-name-map> 2. Foreach attribute whose name you want to map to that in a validation schema create a rule of the form: target="my-element-name[@my-attribute-name]"> <dsrl:attributenamemap schema-attribute-name </dsrl:attribute-name-map> 3. Foreach attribute value token whose name you want to map to that in a validation schema create a rule of the form: target="adresse[@sorte]"> <dsrl:attributevaluesmap my-value1 schema-value1 my-value2 schema-value2 </dsrl:attribute-values-map> 4. Foreach of entity whose name you want to map to that in an entity set a rule of the form: <dsrl:entitynamemap target="adresse[@sorte]"> my-name1 xmlname html-name my-name2 dtd-name my-name3 </dsrl:entity-name-map> 5. Foreach of processing instruction type whose name you want to map to that in a validation schema create a rule of the form: <dsrl:map-pi-target target-name="schema-PI-name" alternative-names="my-PI-name1 my-PI-name2"/> In addition you can manage the values of attributes and the content of elements: 1. Foreach attribute that you want to give a default value to create a rule of the form: <dsrl:default-attribute-values target="my-element-name"> attribute-name attribute-value </dsrl:default-attribute-values> 2. Foreach element that you want to give a default value to create a rule of the form: <dsrl:default-content target="my-element-name" parent="parent-element-name" map-to-element-name="schema-element-name" force-default="true"> Default content </dsrl:default-content> Other techniques provided in the DSRL standard allow you to: 1. Recordyour translation requirements as attributes of an element in a document instance: <my-element-name dsrl:element-name-map=”schema-element-name”> 2. Recordyour translation requirements as application-specific information in a schema: <appinfo> <dsrl:elementnamemap target="myelementname"> schema-element-name </dsrl:element-name-map> </appinfo>

Using XSLT to process DSRL maps DSDL.ORG provides an XSLT 2.0 transformation,TransformDSRLmap.xsl, that can be used to convert DSRL maps into application-specific XSLT transformations. The example map provided with the transformation rules,MapFrenchToEuropeanAddress.xml, contains examples of the use of each DSRL feature (at the expense of being somewhat unrealistic!). It reads: <?xml version="1.0" encoding="UTF-8"?> <?xml-stylesheet type="text/xsl" href="TransformDSRLmaps.xsl"?> <dsrl:maps xmlns:dsrl="http://purl.oclc.org/dsdl/dsrl">  <dsrl:element-name-map target="adresse" targetNamespace="http:/www.my-co.fr/adresses" targetSchemaLocation="EuropeanAddress.xsd">address</dsrl:element-name-map> <dsrl:attribute-name-map target="adresse[@sorte]"> type</dsrl:attribute-name-map> <dsrl:attribute-values-map target="adresse[@sorte]"> maisonhome bureauoffice </dsrl:attribute-values-map> <dsrl:attribute-name-map target="adresse[@torte]"> type2</dsrl:attribute-name-map> <dsrl:attribute-values-map target="adresse[@torte]"> maisonhome bureauoffice </dsrl:attribute-values-map> <dsrl:element-name-map target="numero"> building-identifier</dsrl:element-name-map> <dsrl:element-name-map target="rue">road</dsrl:element-name-map> <dsrl:element-name-map target="ville">locality</dsrl:element-name-map> <dsrl:element-name-map target="cité">postal-town</dsrl:element-name-map> <dsrl:element-name-map target="département">county</dsrl:element-name-map> <dsrl:element-name-map target="code-postal">postcode</dsrl:element-name-map> <dsrl:element-name-map target="pays">country</dsrl:element-name-map>  <dsrl:entity-name-map> eacutee ampet ampand ltopen-tag gtclose-tag </dsrl:entity-name-map> <dsrl:map-pi-target target-name="PIname" alternative-names="PInameAsInputAlternativePIname"/> <dsrl:map-pi-target target-name="ProcessThis" alternative-names="MyPI"/> <dsrl:default-content target="cité" parent="adresse" map-to-element-name="postal-town" force-default="true"> Bordeaux </dsrl:default-content>

<dsrl:default-content target="ville" parent="adresse" map-to-element-name="locality"> <dsrl:default-attribute-values force-default="false"> requiredfalse </dsrl:default-attribute-values> Downtown </dsrl:default-content>

<dsrl:default-attribute-values target="pays" force-default="true"> code-system iso3166 </dsrl:default-attribute-values> </dsrl:maps>

When this file is transformed byTransformDSRLmap.xsl, it produces an XSLT stylesheet, DSRLtransform.xslin the example suite, that can be used to convert French addresses to their European equivalents. For example, the unrepresentative test file:

<?xml version="1.0" encoding="UTF-8"?> <?xml-stylesheet type="text/xsl" href="DSRLtransform.xsl"?> <!DOCTYPE doc SYSTEM "Adresse.dtd" [ <!ENTITY e "é"> ]> <?AlternativePIname PI proceeds root?> <doc xmlns:xi="http://www.w3.org/2001/XInclude"> <adresse sorte="maison"> <numero>29</numero> <rue>RueBricot</rue> <ville>Monmartre</ville> <?PInameAsInputEmbedded PI?> <cité>Paris</cité> <département>Îlede France</département> <code-postal>95010</code-postal> <pays>France&open-tag;this&and;that&close-tag;</pays> </adresse> <adresse sorte="bureau"> <numero>2</numero> <rue>AvenueCharles de Gaulle</rue> <?MyPIAnother mapped PI?> <cité>Toulon</cité> <département>Aud&e;&et; Dauphine</département> <code-postal>12345</code-postal> <pays>France</pays> </adresse> </doc> <?AlternativePIname PI follows root?>

will be converted to:

<?xml version="1.0" encoding="UTF-8"?> <?PIname PI proceeds root?><doc xmlns:xi="http://www.w3.org/2001/XInclude"> <addressxmlns="http://csw.co.uk/addresses" targetNamespace="http://csw.co.uk/addresses" targetSchemaLocation="EuropeanAddress.xsd" type="maison"> <building-identifier>29</building-identifier> <road>RueBricot</road> <locality>Monmartre</locality> <?PInameEmbedded PI?><postal-town>Bordeaux</postal-town> <county>Îlede France</county> <postcode>95010</postcode> <countrycode-system="iso3166">France <this&that></country> </address> <addressxmlns="http://csw.co.uk/addresses" targetNamespace="http://csw.co.uk/addresses" targetSchemaLocation="EuropeanAddress.xsd" type="bureau"> <building-identifier>2</building-identifier> <road>AvenueCharles de Gaulle</road> <?ProcessThisAnother mapped PI?><postal-town>Bordeaux</postal-town> <county>Audé& Dauphine</county> <postcode>12345</postcode> <countrycode-system="iso3166">France</country> <locality>Downtown</locality> </address> </doc> <?PIname PI follows root?>
