LC-1 Installation Tutorial ver1-3

LC-1 Installation Tutorial Jason Morris LC-1 Installation Tutorial Copyright © 1998-2005 EFILive Limited All rights reserved First published Oct 16, 2005 Revised Nov 29, 2005 Disclaimer: Information in this document has not been verified. Use at your own risk. Credits: Portions of this document show screenshots from Innovate Motorsports’ LC-1 configuration software.EFILive is a registered trademark of EFILive Limited. LC-1 is a registered trademark of Innovate Motorsports. Acrobat Reader is a registered trademark of Adobe Systems Incorporated. Microsoft Windows is a registered trademark of Microsoft Corporation. All other trademarks belong to their respective owners. LC-1 Installation Tutorial 1. LC-1 Install Description This Tutorial will provide general instructions for the installation, programming and integration of the Innovate LC-1 with EFILive Scan Tools and a DynoTune Display. Please refer to manufacturer’s manuals for details, warnings, and other specific information. Both Analog outputs (“Analog Out 1”- Yellow wire and “Analog Out 2”- Brown wire) from the LC-1 are programmable. Either can be used for any application or display as long as the application/display uses a linear 0-5 Volt analog signal. The LC-1, EFILive/FlashScan, and DynoTune display must be programmed or calibrated to be compatible with each other. A typical LC-1 from the manufacturer will have “Analog Out 1” programmed to ...
