JMS Southbound Tutorial

JMS Southbound Tutorial The list of topics for the preliminary tutorial document is as given below: 1. Introduction 2. Application Overview 3. Application Design 4. Installation 5. Starting 6. Testing Introduction Enterprise Management Applications implement a number of Southbound protocols. Java Messaging Service (JMS) is one of them. This tutorial is aimed at demonstrating how JMS protocol can be used in Web NMS configuration and fault management. Application Overview This application is aimed at invoking the operations in Shopping Cart application and get the result for possible operations. Receive the notifications from the Shopping Cart project and convert it to events/alerts to store in the database This tutorial is in four parts 1. OSS (an RMI Client) to initiate configuration 2. Web NMS to handle the network management functionality (Configuration and Fault Management) 3. JBoss application to provide the JMS support 4. JMX Agent to execute the configuration tasks Handling Configuration Invoke OSS, prepare the configuration task in the XML format and submit it. The XML document consists of the following information about the entity to be configured. • Device o destination (object name of the MBean of the JMX agent should be given) o Operation Name Parameter Name Value Type Web NMS receives the XML document and converts it into configuration tasks. Further the tasks are converted to JMS ...
